Precision Casting Services

One process, applied to five different sets of parts. What changes between them is not the casting — it is which failure matters, and therefore how the part is gated, how the shell is built, and what gets measured on every lot.

Marine and pump hardware

Impellers, valve bodies, sea-water pipe fittings, propeller hardware. The failure that matters is leakage and pitting, so the shell has to survive dewaxing without a hairline crack and the alloy has to be the one on the drawing. Where a part sees chlorides, CF8M and higher-alloy grades behave very differently from CF8, and the difference is not visible on a strength check.

Typical alloys: CF8M, CF3M. Other grades evaluated per drawing.

Automotive and motorcycle components

Brackets, exhaust-side fittings, sensor housings, structural mounts. Volume is the dominant cost driver here, which makes the wax die layout and the parts-per-cluster decision more important than the melting practice. A cluster that runs 60 parts to save cost per piece will often produce a narrower process window than one that runs 40.

Typical alloys: 42CrMo, 4140, CF8, heat-resistant stainless for exhaust-side parts.

Medical and instrument parts

Small, thin, dimensionally tight, often with a cosmetic requirement that rules out post-cast welding. Tolerance and surface finish are the whole conversation, and the parts are usually too small for the finishing department to correct a casting error. This is the category where the 8.5-coat shell and the tighter dimensional band earn their cost.

Typical alloys: 304/316 stainless, plus carbon and low-alloy steels; other grades evaluated per drawing.

Industrial machinery and wear parts

Gear blanks, linkage components, pump wear rings, valve trim. Usually heavy sections with isolated thick bosses, which is the classic shrinkage case: the thin section freezes first and the thick one has nothing left to feed it. Gating and riser placement decide the outcome long before the pour.

Typical alloys: carbon steel, low-alloy steel, cobalt-base wear alloys.

Architectural and decorative hardware

Door hardware, fittings, ornamental components, jewellery-scale parts. Surface finish and colour consistency matter more than mechanical properties, and the same part may need to run in brass, bronze and stainless across a product family. Finishing is where these parts succeed or fail.

Work we do around the casting

Before the pour

  • Drawing review for castability, before quoting
  • Wax die design and manufacture
  • Gating and riser layout, with simulation where the section is difficult
  • Rapid prototype parts from a printed pattern, when the die is not justified yet

After the pour

  • Gate removal, grinding, shot blasting
  • Heat treatment: solution annealing, normalising, precipitation hardening
  • Passivation and pickling for stainless
  • In-house spectro report per heat + dimensional records; third-party testing quoted per project
  • Machining coordination for critical interfaces

Not sure which process fits the part?

Send the drawing. If investment casting is the wrong answer for your volume or geometry, we will say so rather than quote for it.
